2800Nm single speed pneumatic torque wrench
Ever since her foundation, Wavor focus on research, development, sales and service of torque wrench. Her products have been widely applied not only in domestic market, but also in many other countries & areas, which have achieved great reputation!
In the beginning of the new year, Wavor launched a new model of single speed pneumatic torque wrench, PSW-28, which has intense structure and great endurability. The net weight of PSW-28 is 7.5kg, minimum torque 430Nm, maximum torque 2800Nm, which has a wide torque range. This tool could start work with minimum 1 bar air supply, maximum free speed 10.5rpm, drive square 1.5" (25.4mm). Air power supply requirement: 6bar, minimum 800L/min clean & dry compressed air. Within stable and sufficient air power supply, the tool could ensure output accuracy ±5%, repeat accuracy ±3%. The driving system of PSW-28 is the same with PSW-21, with high speed & efficiency air motor, integrated die-casting aluminum shell, which greatly prolonged the working life.
This PSW-28 pneumatic torque wrench could be used for the locking & unlocking job for bolts M24-M42, nuts 36-65mm, completely meet the requirement of high working frequency, especially for explosion-proof industry such as oil, mining.
In the beginning of the new year, Wavor launched a new model of single speed pneumatic torque wrench, PSW-28, which has intense structure and great endurability. The net weight of PSW-28 is 7.5kg, minimum torque 430Nm, maximum torque 2800Nm, which has a wide torque range. This tool could start work with minimum 1 bar air supply, maximum free speed 10.5rpm, drive square 1.5" (25.4mm). Air power supply requirement: 6bar, minimum 800L/min clean & dry compressed air. Within stable and sufficient air power supply, the tool could ensure output accuracy ±5%, repeat accuracy ±3%. The driving system of PSW-28 is the same with PSW-21, with high speed & efficiency air motor, integrated die-casting aluminum shell, which greatly prolonged the working life.
This PSW-28 pneumatic torque wrench could be used for the locking & unlocking job for bolts M24-M42, nuts 36-65mm, completely meet the requirement of high working frequency, especially for explosion-proof industry such as oil, mining.
