◎ Air supply:6bar compressed air, max consumption is 600L/min
◎ Preset torque，output and repeat accuracy:±5% and ±3%
◎ Powerful and low noise, less than 80Dba under load
◎ Free connection of power handle and gear box, could be rotated
     360°
◎ With manual 2-speed gearbox, high/low speed can be shifted
     freely
◎ Reverse pressure-bias motor provide the higher torque when
     removing or loosening bolts
◎ Supply scope: Air register, hose, quick coupling
     (air inlet connector of air register is excluded)


Compressed air releases quickly in air motor and takes a lot of  heat, thus power unit will notheat up obviously under continuous high workload,even in hot summer.



Model	Torque (Nm)	Square  C	Diameter D (mm)	Length L (mm)	Free speed* (rpm)	Weight* (kg)
PTW-14S	200-1400	1"	88	370	22.0	6.7
PTW-29S	410-2900	1"	88	390	9.0	7.3
PTW-40S	560-4000	1-1/2"	96	410	7.0	9.2
PTW-62S	870-6200	1-1/2"	114	445	5.0	11.3
PTW-120S	1880-12000	1-1/2"	143	496	2.0	18.4

*Above weight does not include reaction arm
*Free speed is no load speed at 6bar air pressure under gear 2
